Product Description
Fabric Specifications
Face” 100% Vinyl
Backing” 100% Polyester
Finish/Treatment Resilience?
Bleach Cleanable” Yes
Ratio: 90% Water / 10% Bleach Solution
Weight” 31.0 oz. per linear yd
Thickness” 1.20 mm
Width” 54″
Roll Size” 30 yards
Directional” Yes
Railroaded” No
Performance Characteristics
Abrasion Resistance ASTM D4157 250,000 double rubs*
Tensile Strength ASTM D751 Warp: 101.0 lbs.
Fill: 89.0 lbs.
Tear Strength ASTM D2261 Warp: 7.6 lbs.
Fill: 7.6 lbs.
Seam Slippage ASTM D751 Warp: 54.8 lbs.
Fill: 43.5 lbs.
Colorfastness to Crocking AATCC 8 Dry: 5.0
Wet: 5.0
UV Resistance AATCC 16 200 hours
Adhesion ASTM D751 Warp: 7.5 lbs.
Fill: 6.8 lbs.
Cold Crack CFFA-6 -20? F
Flex ASTM D2097-03 25,000 cycles
Flammability**
CAL TB 117-2013 Passes
NFPA 260 Class 1
UFAC Class 1
IMO 2010 FTP Part 8, 3.1 Passes
IMO 2010 FTP Part 8, 3.1 & 3.2 Passes
FMVSS 302 Passes
Additional Attributes
Prop 65 Compliant” Yes
16P Phthalate Free” Yes
Free of Added FR Chemicals / CAL AB2998 Compliant” Yes
Free of Added Anti-Bacterial Chemicals: Yes
Free of Added Anti-Microbial Chemical: Yes
BPA Free: Yes
Free of Conflict Minerals: Yes
Formaldehyde Free: Yes
Free of Heavy Metals: Yes
Lead Free: Yes
Sulfide Stain Resistant: Yes
TRIS Free: Yes
